¶ Feature
- Designed for General Factory Environment;
- Simple dust proof effect with Stainless Steel Sheet；
- Widely applicable to 3C Industry、Automotive Industry、General Industry；
- Guide build-in,Low Cost,High Performance
¶ Spec
| Repeatability(mm) | 0.01 | ||
| Stoke Pitch(mm) | 50~800(50mm Pitch) | ||
| Motor | 400W | ||
| Ball Screw Lead(mm) | 5 | 10 | 20 |
| Max Speed(mm/s) | 250 | 500 | 1000 |
| Max PlayLoad Horizontal(kg) | 50 | 30 | 18 |
| Max PlayLoad Vertical(kg) | 15 | 8 | 3 |
